CD3000S 2PH Power Controller

CD3000S 2PH is the two-phase version of our low cost family of solid state relays designed to replace the now obsolete contactors.

• Fully isolated from power.
• Zero crossing firing available with logic input signal (SSR)
• Constant current drain with SSR input
• Analog input 4÷20mA or 0÷10V with burst firing 4, 8 or 16 cycle at 50% power demand, is available as an option from 35A to 90A.
• Heater break alarm (HB) to diagnostic partial or total load failure and short circuit on thyristor, is available as an option from 35A to 90A
• Side by side mounting.
• Special design for heatsink with high dissipation
• Comply with EMC specification CE and cUL
