CD3000S 1PH Power Controller

CD3000S 1PH is the single phase version of our low cost family of solid state relays designed to replace the now obsolete contactors.

• Single-phase thyristor units up to 90A.
• Applicable for resistive loads and infrared lamp.
• Zero crossing firing available with logic input signal (SSR)
• Constant current drain with SSR input
• Analog input 4÷20mA or 0÷10V with burst firing 4, 8 or 16 cycle at 50% power demand, is available as an option from 15A to 90A
• Heater break alarm (HB) to diagnostic partial or total load failure and short circuit on thyristor, is available as an option from 15A to 90A
• Side by side mounting
• Special design for heatsink with high dissipation
• IP20 protection
• Comply with EMC specification CE and cUL
